VOLGA HVAC® – 100 Ton (370 kW) Industrial Chiller

VIC-W Series | Water-Cooled Screw Type | R134a / R407C

Heavy-Duty Industrial Cooling Built for Performance

The VOLGA HVAC® VIC-W Series delivers high-capacity cooling performance designed for mission-critical industrial environments. With a range extending from 2.5 TR to over 1000 TR, these water-cooled chillers are optimized for high ambient conditions and continuous-duty cycles.

Applications

Plastic injection molding & PET blowing
CNC machining & process equipment
Water bottling and treatment plants
Food & beverage production
Pharmaceutical & chemical industries
Commercial refrigeration and packaging systems

Key System Features

Skid-mounted, compact design for easy installation
Semi-hermetic screw compressor with low vibration & noise
Shell & tube heat exchangers for efficient thermal transfer
Multi-step capacity modulation: 100%, 75%, 50%, 25% or 100%, 66%, 33%
Eco-friendly refrigerants: R134a, R407C
Stainless steel tank and internals (optional)
Digital control with high-precision temperature display
Heavy-duty water pumps for continuous operation
Automated PLC control panel with LED multi-language interface
Remote access-ready industrial interface

Compressor Protection & Control

Motor winding & discharge temp protection
Oil level & pressure differential monitoring
Flow switch, high/low pressure, phase loss
Anti-freeze & exhaust over-temp control
Approved compressors: Danfoss, Copeland, Panasonic, Hannibal

Optional Design Flexibility

Tailored to meet your exact needs:

Cooling load and thermal specs
Flow rate and water-side pressure
Ambient temperature conditions
Electrical power configuration
Spatial or structural installation limitations

Component Materials

Tube Material: High-grade copper
Fin Type: Finned copper or enhanced aluminum
Casing: Galvanized steel or stainless steel options

Certifications & Quality Compliance

ISO 9001:2015 – Quality Management
ISO 45001:2018 – Occupational Health & Safety
CTI Certified – Cooling Technology Institute
ASO QCMS / CSAMS / OHSMS

Warranty Coverage

12 months from startup or 24 months from delivery (whichever comes first)
Covers replacement of defective components
Optional labor compensation available through prior agreement

Go Green HVAC® Certified

All VOLGA HVAC® chillers are part of the Go Green HVAC® initiative — combining energy-efficient design, responsible refrigerant use, and long-term sustainability in industrial cooling.
